Chemical Requirements |
Type S
(seamless)
|
Type E |
Type F |
||
|
Download Chart |
(electric-
resistance welded)
|
(furnace-
welded pipe)
|
|||
|
|
Grade A |
Grade B |
Grade A |
Grade B |
Grade A |
|
Carbon max. % |
0.25 |
0.30* |
0.25 |
0.30* |
0.3 |
|
Manganese % |
0.95 |
1.2 |
0.95 |
1.2 |
1.2 |
|
Phosphorous, max. % |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
|
Sulfur, max. % |
0.045 |
0.045 |
0.045 |
0.045 |
0.045 |
|
Copper, max.% |
0.40 |
0.40 |
0.40 |
0.40 |
0.4 |
|
Nickel, max. % |
0.40 |
0.40 |
0.40 |
0.40 |
0.4 |
|
Chromium, max. % |
0.40 |
0.40 |
0.40 |
0.40 |
0.4 |
|
Molybdenum, max. % |
0.15 |
0.15 |
0.15 |
0.15 |
0.15 |
|
Vanadium, max. % |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
|
For NPS 1 1/2 and Smaller Sizes |
|
For NPS 2 and Larger Sizes |
|
|
1/64″ over |
1/64″ under |
1% over |
1%under |
|
|
Seamless and Electric-resistance-welded |
Continuous-Welded |
|
|
|
Grade A |
Grade B |
|
|
Tensile Strength, min., psi |
48,000 |
60,000 |
45,000 |
|
Yield Strength, min., psi |
30,000 |
35,000 |
25,000 |
|
|
Degree of Bend |
Diameter of Mandrel |
|
For Normal A53 Uses |
90 |
12 x nom dia. of pipe |
|
For Close Coiling |
180 |
8 x nom dia. of pipe |
Lengths
|
Standard Weight |
|
|
|
Single Random — 16′ – 22′. 5% may be jointers. If Plain Ends — 5% may be 12′ – 16′. |
|
|
Double Random — Shortest Length 22′, minimum average for order 35′. |
|
Extra Strong and Double Extra Strong |
|
|
|
Single Random — 12′ -22′. 5% may be 6′ – 12′. |
|
|
Double Random (XS and lighter) — Shortest Length 22′, minimum average for order 35′. |
|
|
Lengths longer than single random with wall thicknesses heavier than XS subject to negotiation. |
Required Markings on Each Length
(On Tags attached to each Bundle in case of Bundled Pipe)
|
Rolled, Stamped, or Stenciled (Mfrs. Option) |
|
Name brand of manufacturer |
|
Kind of pipe, that is, Continuous Welded, Electric-Resistance-Welded A, Electric-Resistance-Welded B, Seamless A, Seamless B, XS for extra strong, XXS for double extra strong. |
|
ASTM 53 |
|
Length of pipe |
General Information
|
Couplings — Applied handling tight. Couplings, 2″ and smaller straight tapped, other sizes taper tapped. |
|
|
Thread Protection — Applied to pipe 4″ and larger. |
|
|
End Finish (unless otherwise specified) — |
|
|
|
STD or XS, or wall thicknesses less than 0.500 in. (excluding XXS): Plain and beveled |
|
|
All XXS and wall thicknesses over 0.500 in.: Plain end square cut. |
