Alloy Steel tube

Carbon steel pipe,Seamless steel pipe,Welded steel pipe
ASTM A213 T22 Alloy Steel Seamless tubes
ASTM A213 T22 Alloy Steel Seamless tubes

ASTM A213 T22 Alloy Steel Seamless tubes

Size : OD: 9.52-630mm WT: 0.59-40mm, Length: 0.5mtr-20mtr

Standard & Grade :ASTM A 213,ASME SA213/SA213M Grade T2, T5, T9, T11, T12, T22, T91, T92

ASTM A213 Gr. T22 Alloy Seamless Steel Tube, ASME SA213 T22 Alloy steel tubes Manufacturer; ASTM A213 Gr. T22 Alloy Steel SMLS Tubes exporter and supplier,Alloy Steel Grade T22 seamless EN10216-2 Tube

Tubing End: Bevel end, Plain end;

Pipe Process of ASME SA213 T22 Steel tube / ASTM A213 T22 Alloy Steel Seamless tubes:

Round Billet → Material Inspection → Grinding → Cut to Length → Heating → Piercing → Bite mandrel → Hot Rolled → Get Rid of Mandrel → Heat Treatmen t → Size Reducing → Cooling → Straightening → Semi Manufactured Product → Corp End Cutting off → UT/ET TEST or Hydrostatic Test → Marking → Packing → Warehousing

ASTM /ASME

Product Name

Executive Standard

Dimension (mm)

Steel Code / Steel Grade

Seamless Ferritic and Austentic Alloy Steel Boiler, Superheater and Heat-Exchanger Tubes

ASTM A213

Ø9.52~630 x WT0.59~40

T2, T5, T9, T11, T12, T22, T91, T92

Seamless Ferritic Alloy Steel Pipes for High Temperature Use

ASTM A335

Ø10.3~1200 x WT2~200mm

P5, P9, P11, P12, P22, P91, P92

Seamless Carbon and Alloy Steel for Mechanical Tubing

ASTM A519

Ø10.3~323.9 x WT1.65~40mm

4130, 4130X, 4140, 4145


EN

Product Name

Executive Standard

Dimension (mm)

Steel Code / Steel Grade

Seamless Ferritic Alloy Steel Pipes for High Temperature Use

EN10216-2

Ø10.3~323.9 x WT1.65~40mm

13CrMo4-5, 1-CrMo9-10, X10CrMoVNb9-1, 15NiCuMoNb5-6-4

Application of ASME SA213 T22 Steel tube / ASTM A213 T22 Alloy Steel Seamless tubes:

Alloy steel seamless pipe is ideally suitable for chemical, petrochemicals and other energy-related applications. It has characteristics of high corrosion resistance and can be used in a wide range of industrial sectors.
- Chemical industries
- Petrochemical industries
- Energy-related applications
Chemical Composition and Mechanical Properties of ASME SA213 T22 Steel tube / ASTM A213 T22 Alloy Steel Seamless tubes:

DIMENSION TOLERANCES OF ASME SA213 T91 Steel tube / ASTM A213 T91 Alloy Steel Seamless tubes:
