Generally, made of hot dipped, galvanized steel, which offers long-term corrosion resistance, it won’t rot, absorb moisture, split, splinter, swell, warp or burn, thereby providing considerable life-cycle cost savings. While weighing less than the average wood scaffold plank, steel scaffolding is stiffer over any given span, reducing bounce and providing a more stable platform.
|
Specification |
||||
|
The Standards(Verticals) |
||||
|
Code |
Length(mm) |
Tube Thickness |
Tube Diameter |
Surface Treatment |
|
RS-S-3000 |
3000 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-S-2500 |
2500 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-S-2000 |
2000 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-S-1500 |
1500 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-S-1000 |
1000 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-S-500 |
500 |
3/3.25 |
48 |
HDG/Powder coated |
|
The Ledgers(Horizontals) |
||||
|
Code |
Effective Length |
Tube Thickness(mm) |
Tube Diameter |
Surface Treatment |
|
RS-L-2000 |
2000 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-L-1770 |
1770 |
3/3.25 |
48 |
HDG/Powder coated |
|
RS-L1000 |
1000 |
3/3.25 |
48 |
HDG/Powder coated |
|
The Diagonal Brace |
||||
|
Code |
Length(mm) |
Tube Thickness(mm) |
Tube Diameter(mm) |
Surface Treatment |
|
RS-D-2411 |
2411 |
3 |
48 |
HDG/Powder coated |
|
RS-D-2244 |
2244 |
3 |
48 |
HDG/Powder coated |
|
The bracket |
||||
|
Code |
Length(mm) |
Tube Thickness(mm) |
Tube Diameter(mm) |
Surface Treatment |
|
RS-B-730 |
730 |
3 |
48 |
HDG/Powder coated |
|
Plank |
||||
|
Code |
Effective Length(mm) |
Width(mm) |
Height(mm) |
Surface Treatme |
|
GP-2050 |
2050 |
480 |
45 |
HDG |
|
GP-1820 |
1820 |
480 |
45 |
HDG |
|
GP-3000 |
3000 |
240 |
45 |
HDG |
|
GP-2000 |
2000 |
240 |
45 |
HDG |
|
GP-1000 |
1000 |
240 |
45 |
HDG |
|
Hollow Head Jack And Jack Base |
||||
|
Code |
Length(mm) |
Tube Diameter(mm) |
Size of Plate(mm) |
Surface Treatment |
|
JB-H-60038 |
600 |
38 |
150*120*50*4 |
HDG |
|
JB-B-60038 |
600 |
38 |
150*150*4 |
HDG |
